As-Built Documentation & Plant Data Digitisation
We clean up, correct, and digitise your legacy plant drawings and data formats. Raw laser scans become clean 3D CAD models, redlined markups become updated master files, and legacy PDFs become intelligent, tagged drawings, all delivered as an auditable data package.
Overcoming fragmented data across brownfield assets
Operating plants frequently suffer from decades of uncoordinated physical changes and inconsistent document archives.
Messy CAD folders
Multiple file versions, no naming convention, no single source of truth for "the current drawing."
Outdated paper blueprints
Original drawings pre-date the CAD era, or exist only as scanned, unsearchable PDFs.
Unorganized raw scans
Laser scan data sitting as an unregistered point cloud, never converted into a usable model.
3D CAD Modeling Services We Offer
From unregistered laser scans to legacy paper archives, we transform incomplete data into verified, compliant engineering assets.
- Registration and cleanup of raw point cloud data from any major scanner format (.e57, .pts, .ptx, .rcp).
- Conversion into 3D CAD geometry: piping, structural steel, equipment, cable tray.
- Delivered as dumb geometry (visualization, clash checks) or upgraded to intelligent BIM objects on request.
- Formats: .rvt, .dwg, .ifc, .nwd, native point cloud retained on request.
- Field redline and markup incorporation into the master CAD file.
- Legacy 2D drawing cleanup: layer standardization, title block correction, revision control.
- Multi-version reconciliation when several "final" copies exist with no clear authority.
- Key output: a single, current, audit-traceable master drawing set.
- Scanned or PDF-only P&IDs converted into tagged, database-linked intelligent drawings.
- Line list and equipment tag extraction, cross-checked against the source document.
- Compatible output for AVEVA P&ID, AutoCAD Plant 3D, and SmartPlant P&ID environments.
- Key output: a searchable, database-connected P&ID your engineers can actually query.
- Full as-built drawing sets: general arrangement, isometrics, sections, updated to final field condition.
- Data compliance reports mapped to your handover checklist or client specification.
- Format standardization across a full document set before handover to operations.
- Key output: a closeout package that passes a document audit on first submission.
Point Cloud to 3D Outsourcing
Our scanning specialists register raw spatial datasets and extract highly accurate engineering geometry for retrofit planning, tie-in verification, and brownfield modifications.
Your Trusted Plant Data Digitisation Partner
| Input state | Typical service |
|---|---|
| Raw laser scan / point cloud | Point Cloud to 3D Modeling Outsourcing |
| Redlined field markups | CAD Drawing Updating Services |
| Scanned or PDF-only P&IDs | Intelligent P&ID Conversion |
| Post-construction, pre-handover | As-Built Documentation & Compliance Reporting |
Zero-Defect Audit Handover
We do not just redraw legacy files—our multi-tier quality control verifies tags, layer hierarchies, and dimensional consistency against physical reality.
- Full revision control with stamped title blocks
- Tagged database cross-referencing for line lists
- ISO 19650 compliant container structuring
- Document audit clearance on first submission
We deliver documentation you can trust
Eliminate field uncertainties, contractor rework, and regulatory audit non-conformances with verified plant documentation.
Source-Verified Output
Every conversion is checked against the original scan or document, not just visually reviewed.
Any Format In, Standard Format Out
Paper, PDF, raw point cloud, or legacy CAD, delivered in the format your handover checklist requires.
Scoped to Data Volume
A single P&ID or a plant-wide scan, priced against the actual dataset, not a flat day rate.
Compliance Reporting Included
A data compliance report mapped to your specification ships with every closeout package.
